The jetson tx2 uses the pascal gpu architecture first released in the high end nvidia tesla p100.

Nvidia jetson tx2 antenna. So both antennas should be connected. See the nvidia jetson linux driver package developer guide for details about software support for those modules. The jetson tx2 developer kit carrier board supports these jetson modules. Bt is always connected to ant 0 j2009 and wifi connected to ant 0 and ant 1 j2008 on jetson tx2.

In this application bluetooth is not of interest. Siso for 802 11a b g mimo for 802 11n ac. And it s ok if both antennas are orientated differently. There doesn t seem to be any specifics in the documentation for this.

J15 4 pin fan header for 5v pwm fan. Rudi is pre integrated with the nvidia jetson tx2 tx1 supercomputer on module providing 256 cuda cores on the nvidia pascal or maxwell architecture. Jetson tx2 jetson tx2i jetson tx2 4gb and jetson tx1. Connect tech nvidia jetson tx2 tx1 carrier boards do not have connectors for the wifi antenna.

This supercomputer on a module brings true ai computing at the edge with an nvidia pascal gpu up to 8 gb of memory 59 7 gb s of memory bandwidth and a wide range of standard hardware interfaces that offer the perfect fit for a variety of products and form factors. J13 400 pin 8 x 50 connector for the jetson module. The jetson tx2 right delivers twice the performance of its older sibling the jetson tx1 left. Nvidia jetson tx2 is an embedded system on module som with dual core nvidia denver2 quad core arm cortex a57 8gb 128 bit lpddr4 and integrated 256 core pascal gpu.

The jetson tx2 developer kit gives you a fast easy way to develop hardware and software for the jetson tx2 ai supercomputer on a module. The wifi antenna connection can be found on the side of the jetson tx2 tx1 module. In an installation where there is only one antenna available does it matter whch of the two wireless connectors on the tx2 is used. The antennas to your nvidia jetson tx2 developer kit motherboard the hdmi cable to your nvidia jetson tx2 developer kit motherboard the power adapter to your wall socket and nvidia jetson tx2 developer kit motherboard the mouse and keyboard to your usb hub the usb hub to your nvidia jetson tx2 developer kit motherboard.

It supports ieee802 11 a b g n ac. The connector used is a u fl mini rf connector. The system has 4gb lpddr4 memory tx1 or 8gb lpddr4 memory tx2 4k video decode encode wifi bluetooth usb 3 0 can 2 0b usb 2 0 and msata and minipcie expansion. It exposes the hardware capabilities and interfaces of the module and is supported by nvidia jetpack a complete sdk that includes the bsp libraries for deep learning computer vision gpu computing multimedia processing and much more.

Are they frequency specific or can either port support any of the available wifi frequencies.
